1 x Bourns 93 Series Cermet Potentiometer with a 6mm Dia. Shaft, 10kΩ, ±10%, 2W - Bourns

roll over the image to zoom in

£0.00
£10.99
RS 522-5305
Earn0
reward points

In stock: 6

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS-LB 6F


    Bourns

    Bourns 93 Series Cermet Potentiometer with a 6 mm Dia. Shaft, 10kΩ, ±10%, 2W, ±150ppm/°C, Panel Mount (Through Hole)


    • BMUK Part # :-522-5305
    • BrandBourns
    • Mfr. Part No.93R1A-R22-A15L
    •
    •
    • You will get 1 Potentiometer







    Product Details

    16mm 93 Series

    The 93 Series from Bourns are square, single turn, panel control potentiometers. These potentiometers feature virtually infinite electrical circuit isolation and the plastic casing ensures high insulation. Available in a range of different pin-out configurations, these potentiometers are offered with a choice of plastic or metal shafts.

    ±5% independent linearity
    1000 hours load life
    Rotational life of 100,000 cycles

    Linearity (independent)±5%
    Insulation resistance @ 500Vd.c.1000MΩmin.
    Dielectric strength1500Vac (rms)
    Temperature coefficient±150ppm/°C
    Contact resistance variation±1% or 3Ω (whichever is greater)
    End resistance2Ω max.
    Electrical rotation240° ±6°
    Mechanical rotation300° ±5°
    Dimensions:
    Body15.9mm square, D.12.7mm
    ShaftØ6mm L.22mm* (plastic)
    Mounting bushØ10mm L.9mm (metal)
    * measurement includes bush



    Specifications


    		Maximum Resistance10 kΩ

    		Number of Turns1

    		Potentiometer TypeLinear

    		Mounting TypePanel Mount, Through Hole

    		Shaft Diameter6 mm

    		Mounting Hole Diameter10mm

    		Power Rating2W

    		Termination StylePin

    		Tolerance±10%

    		Series93

    		Length34.7mm

    		Depth15.88mm

    		Height17.47mm

    		Dimensions34.7 x 15.88 x 17.47mm

    		Temperature Coefficient±150ppm/°C

    		Maximum Operating Temperature+125°C

    		Minimum Operating Temperature-40°C


    To view the datasheet please Click Here
