1 x Bourns 3299W-1-500LF, Trimmer Resistor with Pin Terminations, 50Ω ±10% 1/2W - Bourns
roll over the image to zoom in
£0.00
£5.49
RS 522-0372
Unit Quantity:
1
Unit Type:
Unit
Bourns
Bourns 3299W Series 25-Turn Through Hole Cermet Trimmer Resistor with Pin Terminations, 50Ω ±10% 1/2W ±100ppm/°C
- BMUK Part # :-522-0372
- BrandBourns
- Mfr. Part No.3299W-1-500LF
- You will get 1 Resistor
Product Details
10mm 3/8 in. 500mW Top Adjust 3299W Series
Bourns® 3299W 3/8" Square Multiturn Cermet Trimming Potentiometer (Trimpot®)
Multi-contact wiper - low noise, high stability
Sealed to withstand immersion board washing
Moulded body with built in stand-offs
Wiper idles at end of travel
Suitable for 0.1in grid pitch
| Power | 0.5W |
| Effective Travel (Nominal) | 25 turns |
| Resistance Tolerance | ±10% |
| Voltage Maximum | 300V |
| Temperature Coefficient | ±100ppm/°C |
| End Resistance | 1% or 2Ω (whichever is greater) |
| Operating Torque | 3.0 oz.in. |
| Rotational Life | 200 Cycles |
| Operating Temperature | -55°C → +125°C |
| Contact Resistance Variation (Max.) | 1% or 3 Ω (whichever is greater) |
| Dimensions | 9.53 x 6.1 x 10 mm |
| Lead Pitch | 2.5 mm |
| Pin diameter | 0.5mm |
| Linear Or Logarithmic | Linear |
Multi Turn 10mm Cermet
Specifications
| Maximum Resistance | 50 Ω | |
| Number of Turns | 25 | |
| Mounting Type | Through Hole | |
| Power Rating | 1/2W | |
| Series | 3299W | |
| Orientation | Top Adjust | |
| Termination Style | Pin | |
| Length | 9.53mm | |
| Depth | 6.1mm | |
| Height | 11.55mm | |
| Dimensions | 9.53 x 6.1 x 11.55mm | |
| Shaft Diameter | 2.29 mm | |
| Tolerance | ±10% | |
| Minimum Operating Temperature | -55°C | |
| Temperature Coefficient | ±100ppm/°C | |
| Maximum Operating Temperature | +125°C |
For a Specification PDF Please CLICK HERE
