1 x BGA6489 Wideband RF Power Amplifier 15 dB, f > 2.5 GHz, 50 Ohm 4-Pin SOT-89 - NXP
roll over the image to zoom in
£0.00
£6.99
RS 626-3544
Unit Quantity:
1
Location:
TS 27B AND APR BOX STACK +
NXP
BGA6489 Wideband RF Power Amplifier 15 dB, f > 2.5 GHz, 4-Pin SOT-89
You get 1 RF Amp on SM Tape,
FEATURES
· Broadband 50 W gain block
· 20 dBm output power
· SOT89 package
· Single supply voltage needed.
APPLICATIONS
· Broadband medium power gain blocks
· Small signal high linearity amplifiers
· Variable gain and high output power in combination with the BGA2031
· Cellular, PCS and CDPD
· IF/RF buffer amplifier
· Wireless data SONET
· Oscillator amplifier, final PA
· Drivers for CATV amplifier.
DESCRIPTION
Silicon Monolithic Microwave Integrated Circuit (MMIC)
wideband medium power amplifier with internal matching
circuit in a 4-pin SOT89 plastic low thermal resistance
SMD package.
The BGA6x89 series of medium power gain blocks are
resistive feedback Darlington configured amplifiers.
Resistive feedback provides large bandwidth with high
accuracy.
Product Details
RF Amplifiers
Specifications
| Amplifier Type | Power | |
| Dimensions | 4.6 x 2.6 x 1.6mm | |
| Height | 1.6mm | |
| Length | 4.6mm | |
| Maximum Operating Temperature | +150 °C | |
| Mounting Type | Surface Mount | |
| Number of Channels per Chip | 1 | |
| Package Type | UPAK | |
| Pin Count | 4 | |
| Typical Noise Figure | 3.4dB | |
| Typical Output Power | 17dBm | |
| Typical Power Gain | 15 dB | |
| Width | 2.6mm |
For a specification PDF Please CLICK HERE
