1 x Astec Isolated DC-DC Converter ASA00BB18-L, Vin 9-36V dc, Vout ±12V dc - Astec
roll over the image to zoom in
£0.00
£31.95
RS 149-017
Unit Quantity:
1
Unit Type:
Unit
Location:
TS BRA-4G
Astec
Astec Isolated DC-DC Converter, Vin 9 → 36 V dc, Vout ±12V dc, I/O isolation 1500V dc
- BMUK Part # :-149-017
- BrandAstec
- Mfr. Part No.ASA00BB18-L
- You will get 1 DC-DC Converter
Product Details
Astec 6W Single/Dual Output, Regulated, Isolated DC-DC Converter - ASA-6W Series
6W regulated, isolated DC-DC converter with a wide 4:1 input range and a 1.25in x 0.8in package. This isolated DC-DC converter is available with single or dual outputs.
Ultra-wide 4:1 input voltage range
Regulated outputs
1.5kV input/output isolation
Built-in filter meets EN 55022, Class A, without external components
Under voltage lockout, over current and short circuit protection with auto restart
Shielded metal case with insulated baseplate
Demonstrated MTBF >1 million hours
24-pin DIP with industry standard pin-out
| Connection data | ||
| Pin | Single Output | Dual Output |
| 2 | -Vin | -Vin |
| 3 | -Vin | -Vin |
| 9 | NC | Common |
| 11 | NC | -Vin |
| 14 | +V out | +V out |
| 16 | -V out | Common |
| 22 | +Vin | +Vin |
| 23 | +Vin | +Vin |
Note
Operating temperature is without derating.
Standards
EN60950 (up to SELV limit)
Astec - 6W to 15W - ASA-6W, ASA-10W, AEE-15W Series
Specifications
| Output Voltage | ±12V dc | |
| Input Voltage Range | 9 → 36 V dc | |
| Input Voltage Nominal | 18 V dc | |
| Isolation Voltage | 1500V dc | |
| Output Current | 250mA | |
| Mounting Type | Through Hole | |
| Number of Outputs | 2 | |
| Package | DIP | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +71°C | |
| Depth | 10.16mm | |
| Length | 31.75mm |
