1 x Arcol Aluminium Wire Wound Resistor HS100 100R J, 100Ω ±5% 100W - Arcol

roll over the image to zoom in

£0.00
£11.99
RS 188-188
Earn0
reward points

In stock: 3

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS-ES 9G


    Arcol

    Arcol HS100 Series Aluminium Housed Axial Wire Wound Panel Mount Resistor, 100Ω ±5% 100W


    • BMUK Part # :-188-188
    • BrandArcol
    • Mfr. Part No.HS100 100R J
    •
    •
    • You will get 1 Resistor












    Product Details

    100W Aluminium housed wirewound power resistor, HS Series

    100Watt Aluminium housed power resistors which are manufactured to be compliant with the requirements of a MIL 18546, IEC 115 and are RoHS compliant. HS Series of high power, aluminium housed resistors offers an unequalled balance of pulse power capability versus volume. An advanced design optimises stability, linearity and reliability, making the HS Resistors suitable for many applications.



    Features

    Compact size for Power rating
    Winding construction maximises High Pulse Capability

    Applications

    Braking resistor
    Inrush limiter
    Inverter/converter
    Snubber
    Balancing resistor



    Power At 25°C100W with 1.0°C/W Heatsink, 50W without Heatsink
    Resistance Tolerance±5%
    Temperature Coefficient<1KΩ ±100ppm/°C,>1KΩ ±25ppm/°C
    Operating Temperature-55°C → +200°C
    Limiting Element Voltage1900Vdc/Vac (rms)
    Insulating Resistance10000MΩ
    Length88 mm
    Width47.5 mm
    Height24.1 mm
    Weight115 g

    Note

    To achieve the given maximum performance rating of this power resistor, it is designed to be directly mounted on an appropriately matched heatsink and mounted using a thermal compound.

    Aluminium Housed, Wirewound - 5 to 600W

    Specifications


    		Resistance100 Ω

    		Power Rating100W

    		SeriesHS100

    		Package/CaseAluminium Housed

    		Tolerance±5%

    		TechnologyWire Wound

    		Termination StyleAxial

    		Minimum Temperature Coefficient-100ppm/°C

    		Maximum Temperature Coefficient+100ppm/°C

    		Temperature Coefficient±100ppm/°C

    		Overall Width47.5mm

    		Dimensions24.1 x 88 x 47.5mm

    		Overall Height24.1mm

    		Overall Length88mm


    To view the datasheet please Click Here
