1 x Analog Devices AD8044ANZ, Quad Op Amp, 150MHz Rail-Rail, 5V, 9V, 14-Pin - Analog Devices
roll over the image to zoom in
£0.00
£14.99
RS 538-4117
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 27C & TS-LB 5K
Analog Devices
Analog Devices AD8044ANZ, Quad Op Amp, 150MHz Rail-Rail, 5 V, 9 V, 14-Pin PDIP
- BMUK Part # :-538-4117
- BrandAnalog Devices
- Mfr. Part No.AD8044ANZ
-
- You will get 1 Op Amp
Product Details
Video Operational Amplifiers, Analog Devices
An economic high speed op amp from Analog Devices, suitable for for a range of applications.
Video Operational Amplifiers
Specifications
| Mounting Type | Through Hole | |
| Package Type | PDIP | |
| Power Supply Type | Dual, Single | |
| Number of Channels per Chip | 4 | |
| Pin Count | 14 | |
| Typical Single Supply Voltage | 5 V, 9 V | |
| Typical Gain Bandwidth Product | 150MHz | |
| Output Type | Rail to Rail | |
| Typical Dual Supply Voltage | ±3 V, ±5 V | |
| Typical Slew Rate | 170V/µs | |
| Minimum Operating Temperature | -40 °C | |
| Maximum Operating Temperature | +85 °C | |
| Height | 3.43mm | |
| Typical Voltage Gain | 94 dB | |
| Typical Input Voltage Noise Density | 16nV/√Hz | |
| Dimensions | 16.89 x 7.24 x 3.43mm | |
| Length | 16.89mm | |
| Width | 7.24mm |
