1 x Analog Devices AD5557CRUZ, 2-channel 14bit Parallel DAC, 2Msps, 38-Pin - Analog Devices

roll over the image to zoom in

£0.00
£30.99
RS 709-5926
Earn0
reward points

In stock: 2

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS BRA10M


    Analog Devices

    Analog Devices AD5557CRUZ, 2-channel 14 bit Parallel DAC, 2Msps, 38-Pin TSSOP

    • BMUK Part # :-709-5926
    • BrandAnalog Devices
    • Mfr Part No.AD5557CRUZ
    •  Analog Devices
    •
    • You will get 1 DAC
    Analog Devices AD5557CRUZ, 2-channel 14 bit Parallel DAC, 2Msps, 38-Pin TSSOP
    Product Details

    Digital to Analogue Converters 14 Bit, Analog Devices

    This family of digital-to-analogue converters (DACs) from Analog Devices come with a 14-bit resolution. Analog Devices' 14-bit DACs are ideal for industrial environments which require a robust design solution. They offer high performance alongside accurate and reliable conversion.





    Digital to Analogue Converters - Analog Devices

    Specifications

    Architecture
    R-2R, Resistor String
    Maximum Operating Temperature
    +125 °C
    Output Polarity
    Unipolar
    Length
    9.7mm
    Typical Single Supply Voltage
    5 V
    Brand
    Analog Devices
    Voltage Reference
    External
    Power Supply Type
    Single
    Digital Interface Type
    Parallel
    Package Type
    TSSOP
    Mounting Type
    Surface Mount
    Conversion Rate
    2Msps
    Minimum Operating Temperature
    -40 °C
    Width
    4.4mm
    Integral Nonlinearity Error
    ±1LSB
    Resolution
    14 bit
    Height
    1.05mm
    Pin Count
    38
    Maximum Settling Time
    0.5µs
    Dimensions
    9.7 x 4.4 x 1.05mm
    Number of DAC Channels
    2
    Full Scale Error
    ±4mV
