1 x AKER 20MHz Crystal ±30ppm SMD 4-Pin 3.2 x 2.5 x 0.75mm - AKER

roll over the image to zoom in

£0.00
£5.99
RS 671-9536
Earn0
reward points

In stock: 149

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    APR BOX Y
    Oscillator Frequency:
    20 MHz


    AKER

    AKER 20MHz Crystal ±30ppm SMD 4-Pin 3.2 x 2.5 x 0.75mm

    • BMUK Stock No.671-9536
    • BrandAKER
    • Mfr Part No.C3E-20.000-12-3030-X
    •
    • You will get ONE crystal
    AKER 20MHz Crystal ±30ppm SMD 4-Pin 3.2 x 2.5 x 0.75mm
    Product Details

    C3E Microprocessor Crystal Unit

    From AKER, these SMD C3E series microprocessor crystal units are low profile and packaged in ceramic with a seam-sealed metal lid. These crystal units offer a good standard of environmental parameters in relation to shock, vibration and operating temperature range.

    https://media.rs-online.com/t_large/L6719514-01.jpg

    Crystals 3.2x2.5mm Ceramic case

    Specifications
    Maximum Operating Temperature
    +85 °C
    Standard Frequency
    20MHz
    Length
    3.2mm
    Load Capacitance
    12pF
    Brand
    AKER
    Package Type
    SMD
    Mounting Type
    Surface Mount
    Minimum Operating Temperature
    -40 °C
    Width
    2.5mm
    Series Resistance
    100Ω
    Height
    0.75mm
    Pin Count
    4
    Dimensions
    3.2 x 2.5 x 0.75mm
    Frequency Tolerance
    ±30ppm
    Frequency Stability
    ±30ppm
