1 x Abb A Line A9 3 Pole, 3NO, 27A, 5.5kW, 230V ac @ 50Hz, 240V ac @ 60Hz Coil - ABB
roll over the image to zoom in
£0.00
£76.59
RS 445-0954
Unit Quantity:
1
Unit Type:
Unit
Location:
ES-4A
ABB
A Line A9 3 Pole Contactor, 3NO, 27 A, 5.5 kW, 230 V ac @ 50 Hz, 240 V ac @ 60 Hz Coil, Screw Terminal
- BMUK Part # :- 445-0954
- BrandABB
- Mfr. Part No.1SBL161001R8810
-
- You will get 1 Contactor
Product Details
A Series AC Controlled Contactors
Three main poles
One N/O auxiliary contact
Front and side mounted auxiliary contact blocks
Location for surge protection
DIN rail and back plate mounting
Manufactured to IEC947-4-1, EN60 047-4-1
CE marked
Note
For Overloads see 455-7797, 456-0196 and similar products.
Approvals
UL, CSA, BV, DNV, GL, LROS, PRS and RINA
Specifications
| Range | A Line | |
| Series | A9 | |
| Number of Poles | 3 | |
| Coil Voltage | 230 V ac @ 50 Hz, 240 V ac @ 60 Hz | |
| Contact Current Rating | 27 A | |
| Contact Voltage Rating | 690 V ac | |
| Normal State Configuration | 3NO | |
| Number Of Auxiliary Contacts | 1 | |
| Power Rating | 5.5 kW | |
| Terminal Type | Screw | |
| Length | 74mm | |
| Width | 44mm | |
| Dimensions | 74 x 44 x 74 mm | |
| Operating Temperature Range | -40 → +55 °C | |
| Depth | 74mm | |
| CAD Drawing | 3D CAD Model | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +55°C |
